Chapter 2 - Toa (Race)

Vendor Chapter 2
Regular price $3,269.00
Sale price $3,269.00 Regular price
Sale Contact to Order
Unit price
/per
Color:
Aqua Blue
Origin
Grey
White Pink
Size:
This is a pre order item. We will ship it when it comes in stock.

TOA

Meaing "To be victorious, win" in Moari



After 2-½ years of rigorous development, CHAPTER2 introduces the TOA Race bicycle as the pinnacle of all frames that came before it. 'TOA', which means 'to be victorious, win' in Maori, is a full-carbon frame optimized for race performance and crafted to the highest of standards. Taking after the TERE's performance all-road capabilities and the AO's versatility, the TOA is designed with tucked-away cables and hoses for a smooth, aerodynamic transition from the MANA Bar to the Kamm-Tail chassis. Featuring a T47 bottom bracket for easy upkeep and a latex mandrel for increased headtube stiffness of 23.5% over the TERE, the TOA possesses additional enhancements such as bundled MANA Bar parts, Quick-Fit headset spacers, up to 32mm tire clearance, and vibration dampening Seatstays and Seatpost.



Features

  • Sleek Racing Frame: Enhanced Energy Transfer & Accurate Steering
  • Cable Integration: Superior Aerodynamics & Minimalistic Design
  • Compact Kamm-Tail: Aerodynamic & Rigidity Where Essential
  • Up to 32mm Tire Clearance: Expanded Tire Possibilities
  • Dropped Stays: Increased Resilience for Prolonged Rides
  • T47 BB: Low-Noise & Maintenance-Friendly
  • Disc Brakes Only: Enhanced Stopping & Controllability
  • Frameset Only: Custom-Made & Exclusive
  • Limited Edition: Uniqueness



Technical Specs

Carbon: 100% Made in Japan by Toray
Frame 6 Sizes: XXS, XS, S, M, L & XL
Fork Rakes (2): XXS, XS, S (53mm offset) and M, L, XL (43mm offset)
Frame Weight: 1,099g (Disc) Size M +/- 3%
Fork Weight: 419g (Disc) Uncut +/- 3%
Seatpost Weight: 135g Size M +/- 3%
Handlebar/Stem (MANA): 395g (100-420mm) +/- 3%
Headset: 1.5” C2 Integrated System
Gear Shifting Type: Mechanical & Electric Shifting
Electronic Shifting: SHIMANO® Di2, SRAM® eTAP & Campagnolo® EPS compatible
Battery Type: Di2 SM-BTR-2 or BT-DN300 and EPS V3 Battery Compatible
Tire Clearance: 30mm (ISO) & 32mm Practical
Brake Type: Disc Only
Bottom Bracket: Internal T47
Thru-Axle: Flat Mount FR 12x100mm, RR 12x142mm, E-Thru M12x1.5mm
Safety Standard: EN ISO 4210:2014
UCI Accreditation: UCI Approved

FAQ

Coming soon! Call our store and talk to our knowledgeable staff
